Core Count: 4P
Category: Male
Direction:110°
Applications: Power, Signal
110-degree all-metal assembled soldered wire type:
Precisely adapted bending angle space: The 110-degree bending angle is specially designed for "non-rectangular gaps at the edges of equipment". Before selecting the model, it is necessary to measure the angle and space of the installation area to ensure that the two sides of the bending angle are in contact with the equipment shell and avoid the rigid friction between the metal shell and other components after assembly; Component inspection first: Before assembly, check the metal shell, insulating base, shielding ring, etc., to ensure there are no cracks, deformations, or burrs. The stress concentration area of the 110-degree bending angle needs to be particularly checked; Sealing rubber rings need to be confirmed to be free of aging, stickiness, and the size should be precisely matched with the slot. Bending cable fixation: After the welding is completed and cooled, the cable needs to be fixed along the natural direction of the 110-degree bending angle. A tie can be used to fix the cable on the equipment bracket to avoid the cable being pulled by its own weight or external force causing the solder joint to crack. The bending radius of the cable needs to be ≥ 6 times the diameter of the cable.
|
Product model
|
Core
|
Rated current
|
Rated voltage
|
Wire gauge / Dimension
|
||
|
A/C
|
D/C
|
AWG
|
mm²
|
|||
| MC12DM-04N4LPLSR601 |
4
|
4A
|
250V
|
250V
|
22
|
0.34
|
| Core | 2A | 3A | 4A | 5A |
| male end |
|
|
|
 |
| 6A | 8A | 12A | 17A | |
|
|
|
|
|
|
| 4B | 5B | 3C | 4C | |
|
|
|
|
|
|
| 5C | 6C | 4D | ||
|
|
|
|
||
| Core | 2A | 3A | 4A | 5A |
| female connector |
|
|
|
|
| 6A | 8A | 12A | 17A | |
|
|
|
|
|
|
| 4B | 5B | 3C | 4C | |
|
|
|
|
|
|
| 5C | 6C | 4D | ||
|
|
|
|
|
The connector must not be plugged or unplugged under load. Failure to follow the instructions and improper use can result in personal injury.
The development of the connector is aimed at being applied in factory engineering, control and electrical equipment construction. Users are responsible for checking whether the connector can also be used in other applications.
Connectors used in circuits with dangerous voltages that cause electric shock must be installed and used only by personnel who have received training in electrical engineering, or under their supervision, while taking into account the applicable regulations and standards.
Users must take appropriate security measures to ensure that the connectors do not accidentally disconnect.
When installing, apply moderate force and use the special tool to tighten the nuts. Avoid excessive force to prevent the shell from deforming or the pins from bending. Ensure that the plug and socket are fully engaged. Do not power on the device when not locked in place to prevent arc discharge due to poor contact.
The plug connectors with an enclosure protection rating of IP67 and IP68 are not suitable for use in water. When used outdoors, the plug connectors must be protected against corrosion separately. For further information on IP protection ratings, please refer to "Technical Information".
